Description

Camera Specifications

Image Sensor

• Type: 2 MP CMOS
• Max. Resolution: 1920 (H) × 1080 (V)

Minimum Illumination

• 0.0005 Lux: @ (F1.0, AGC ON)
• 0 Lux: with white light

Shutter Time

• PAL: 1/25 s to 1/50,000 s
• NTSC: 1/30 s to 1/50,000 s

Day & Night

• ICR: Yes

Angle Adjustment

• Pan: 0° to 360°
• Tilt: 0° to 75°
• Rotation: 0° to 360°

Signal System

• PAL/NTSC

Slow Shutter

• Max: 16 times

Lens

• Type: 2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV:
  • 2.8 mm: Horizontal FOV: 105°, Vertical FOV: 56°, Diagonal FOV: 123°
  • 3.6 mm: Horizontal FOV: 85°, Vertical FOV: 46°, Diagonal FOV: 98°
• Mount: M12

Illuminator

• Supplement Light Type: IR, White Light
• Smart Supplement Light: Yes
• Supplement Light Range: IR: Up to 40 m, White Light: Up to 40 m


• Image Parameters Switch: STD/HIGH-SAT/HIGHLIGHT
• Image Settings: Brightness, Contrast, Sharpness, Anti-banding, AGC

Frame Rate

• TVI: 1080p @30 fps, 1080p @25 fps

Day/Night Mode

• Auto

Wide Dynamic Range (WDR)

• WDR: ≥130 dB

Privacy Mask

• 4 programmable privacy masks

Image Enhancement

• WDR, BLC, HLC, Global, HLS

Noise Reduction

• 3D DNR

White Balance

• Auto, Manual

Interface

• Video Output: 1 HD analog output
• Alarm: Solid Light Alarm (White Light)
• Built-In Microphone: Yes

Event

• Motion Detection: 4 programmable motion areas

General

• Material:
  • Main Body: Metal
  • Enclosure: Plastic
• Dimension: Ø109.98 mm × 98.27 mm (Ø4.33″ × 3.87″)
• Weight: Approx. 365 g (0.81 lb.)

Operating Condition

• -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensing)

Communication

• HIKVISION-C

Language

• English

Power

• 12 VDC±25%/PoC.at, Max. 5.1 W
  • You are recommended to use one power adapter to supply power for one camera.

Approval

• Protection: IP67
