Description

Camera Specifications

Image Sensor

• Resolution: 8 MP CMOS
• Signal System: PAL/NTSC
• Max. Resolution: 3840 (H) × 2160 (V)
• Min. Illumination: 0.0005 Lux@(F1.0, AGC ON), 0 Lux with white light
• Shutter Time:
  • PAL: 1/12.5 s to 1/50,000 s
  • NTSC: 1/15 s to 1/50,000 s
• Day & Night: 24/7 Color Imaging

Angle Adjustment

• Pan: 0° to 360°
• Tilt: 0° to 180°
• Rotation: 0° to 360°

Lens

• Type: 2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV:
  • 2.8 mm: Horizontal FOV: 110°, Vertical FOV: 59°, Diagonal FOV: 131°
  • 3.6 mm: Horizontal FOV: 93°, Vertical FOV: 48°, Diagonal FOV: 113°
• Mount: M16

Illuminator

• Supplement Light Type: White Light
• Supplement Light Range: Up to 40 m


• Frame Rate:
  • TVI: 8 MP @ 12.5 fps/15 fps, 3K @ 20 fps, 1080P @ 25 fps/30 fps
• Wide Dynamic Range (WDR): ≥130 dB
• Image Parameters Switch: STD/HIGH-SAT/HIGHLIGHT
• Day/Night Mode: Color
• White Balance: Auto/Manual
• Image Enhancement: WDR, BLC, HLC, Global, HLS
• Privacy Mask: 4 programmable privacy masks
• Noise Reduction: 3D DNR/2D DNR
• Image Settings: Brightness, Contrast, Mirror, Sharpness, Anti-Banding, Smart Light, AGC

Interface

• Video Output: 1 HD analog output
• Alarm: Solid Light Alarm (White Light)
• Event: Motion Detection (4 programmable motion areas)

General

• Language: English
• Operating Condition: -40°C to 50°C (-40°F to 130°F), Humidity: 90% or less (non-condensing)
• Material: Main body: Metal, Enclosure: Plastic
• Communication: HIKVISION-C
• Dimension: Ø109.98 mm × 98.27 mm (4.33″ × 3.87″)
• Weight: Approx. 350 g (0.77 lb.)
• Power: 12 VDC ± 25%/PoC.at, Max. 5.1 W

Note: It’s recommended to use one power adapter for one camera, and use the 2-pin power supply for long-distance power supply.

Approval

• Protection: IP67
