Description

Camera Specifications:

Image Sensor: 2 MP CMOS

Max. Resolution: 1920 (H) × 1080 (V)

Min. Illumination: 0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR

Shutter Time: PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s

Day & Night: ICR

Angle Adjustment: Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°

Signal System:

PAL/NTSC

Lens:

• Lens Type: 2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV:2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118 | 3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°
• Lens Mount: M12

Illuminator:

• Supplement Light Type: White Light; IR
• Supplement Light Range: IR: Up to 30 m | White Light: Up to 20 m

Image:

• Image Settings: Brightness, Sharpness, Smart IR
• Frame Rate:
  • TVI: 1080P @ 30 fps, 1080P @ 25 fps
  • AHD: 1080P @ 30 fps, 1080P @ 25 fps
  • CVI: 1080P @ 30 fps, 1080P @ 25 fps
  • CVBS: PAL/NTSC
• Day/Night Mode: Auto/Color/BW (Black and White)
• Wide Dynamic Range (WDR): Digital WDR
• Image Enhancement: DWDR/BLC/HLC/Global
• White Balance: Auto/Manual
• AGC: Yes

Interface:

• Video Output: Switchable TVI/AHD/CVI/CVBS
• Built-In Microphone: Yes

General:

• Material: Metal
• Dimension: 80 mm × Ø85.1 mm (3.1″ × Ø3.4″)
• Weight: Approx. 296 g (0.65 lb.)
• Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)

Communication:

• HIKVISION-C

Language: English

Power Supply: 12 VDC ± 25%

• You are recommended to use one power adapter to supply power for one camera.

Consumption: Max. 3.3 W

Approval:

Protection: IP67
