Description

Dimension Parameters:

• Tunnel Size: 500mm (W) × 300mm (H)

Specification Parameters:

• Max. Load: 100 kg (220.46 lb)
• Conveyor Speed: 0.22 m/s

Performance Parameters:

• Penetration: Standard 8mm, customizable up to 10+ mm
• Wire Resolution: 40AWG

Spatial Resolution:

• • Vertical: 1.0 mm (0.04″)
  • Horizontal: 1.0 mm (0.04″)

General Standard:

• Power Consumption: 0.5 kW
• Weight: 290 kg (639.34 lb)

Radiation Dose:

• X-Ray Dose Per Inspection: < 5 μGy
• X-Ray Leakage: < 1 μGy/h

Other Parameters:

• X-Ray Generator: Anode Voltage: Standard 80 kV, 100% Oil Cooling

General:

• Power Supply: 220 VAC/110 VAC (-10% to +15%), 50 Hz /60 Hz (±3 Hz)
• Working Temperature: 0 °C to 40 °C (41 °F to 104 °F)
• Working Humidity: 0% to 90%
• Dimension: 1586mm × 1160mm × 760mm (L x H x W)
