Description

Networking Function:

• Can be single-machine networking
• Configuration through the web terminal for parameter settings

Metal Detection:

• Can detect metal objects as small as 1 coin size
• Effective for verifying illegal items

Ultra-low Detection Height:

• Can detect metal objects more than 3cm above the ground in the detection area

Boot Self-diagnostic Function:

• Performs a self-test on the system at boot time
• Displays the test results

Display:

• 7-inch LCD color screen display
• Displays menu, number of people passing through, metal alarm number, and other information

Multi-zone Alarm Function:

• Alarms multiple metals in different positions of the human body simultaneously
• Can indicate the position of multiple metals
• Supports up to 12 zones

Modular Component Design:

• Facilitates easy and fast transportation and maintenance

Flying Object Alarm Function:

• Accurately alarm metal objects thrown from the middle of the door

Dimension Parameters:

• Tunnel Size: 2000mm (H) x 710mm (W) x 500mm (D)
• Overall Dimensions: 2200mm (H) x 840mm (W) x 600mm (D)

Specification Parameters:

• Operating Temperature: -20°C to 55°C
• Power: 220V
• Weight: Less than 75kg
