Description

Here are the optical and technical specifications for the projector:

Display Technology: Single 0.47” 4K UHD DMD DLP® Technology by Texas Instruments™

Color Wheel: RGBRGB 6 Segment color wheel

Native Resolution: 4K UHD 3840×2160 @ 60Hz with XPR Technology

Maximum Resolution: 4K 4096×2160 @ 60Hz

Brightness: 2,400 ANSI lumens

Contrast Ratio: Up to 500,000:1 with Dynamic Black

Color Gamut Support:

• REC.709 color gamut provides rich, accurate color based on the HDTV broadcast specification and used with all non-HDR content.
• DCI-P3 wide color gamut is the equivalent to color in the CIE 1931 color space, resulting in vivid colors.

HDR (High Dynamic Range): HDR10 compatible (REC.2020)

Picture Modes: Normal, Bright, Detail, Film, HDR SIM (simulate HDR effect with non-HDR content)

4K UHD Upscale: Upscales WXGA, 720p, 1080p, WUXGA, 1440p resolutions and frame rates up to 4K UHD (3840×2160), 60 Hz

Video Processing: UltraDetail Technology enhances image quality by improving image depth and clarity

Color Depth: Various YUV 4:4:4, 4:2:2, 4:2:0 options in 8bit, 10bit, and 12bit

Lamp Life and Type: 4000/10,000/15,000 hours (Bright/ECO/Dynamic)

Projection Method: Front, rear, ceiling mount, table top

Vertical Lens Shift: 15% offset (with tolerance ±5%)

Keystone: ±40°

Uniformity: 80%

Offset: 100%

Aspect Ratio: 16:9 (native), 4:3 and LBX compatible

Throw Ratio: 1.21 – 1.59 (with tolerance ±5%)

Projection Distance: 2.9’ – 34.89’

Image Size: 34.1” – 302.4” (34.1” to 140” optimal image size)

Projection Lens: F=2.5~ 3.26, f=20.91 ~ 32.62 mm manual focus

Optical Zoom: 1.3x

Digital Zoom: 0.8 – 2.0

Audio: 2x5W speakers (stereo)

Noise Level: 28/25dB (Bright/ECO)

Remote Control: Full-function home remote control

Operating Temperature: 41–104°F (5–40°C), 85% max humidity

Power Supply: AC input 100–240V, 50–60Hz, auto-switching

Power Consumption:

• 317W typical (Bright mode)
• 348W max (Bright mode)
• 259W typical (Eco+ mode)
• 285W max (Eco+ mode)

High Altitude Operating Temp: At sea level to 10,000 feet = 23°C (max); must manually switch to high altitude mode at 5000 feet & above (using OSD)

Computer Compatibility: Various resolutions including 4K UHD 2160p, WUXGA, HDTV 1080p, UXGA, SXGA, WXGA+, WXGA, HDTV (720p), XGA, SVGA, VGA, PC, and Mac compatible

Video Compatibility: Supports various resolutions and frame rates including 4K UHD 2160p, 1080p, 1080i, 720p, 480i/p, 576i/p

HDR Source Compatibility: Ultra HD Blu-Ray player, 4K UHD streaming media device, Xbox One S / One X, and PS4 Pro (for specific HDR content)

3D Compatibility: Supports various 3D formats such as side-by-side, Blu-ray 3D, frame-pack, and over-under

Vertical Scan Rate: 24Hz to 120Hz

Horizontal Scan Rate: 31.000 to 135.000KHz

User Controls: Yes

I/O Connection Ports:

• HDMI 2.0 (w/ HDCP 2.2, MHL 2.1)
• HDMI 1.4a
• VGA-in
• Audio-in (3.5mm)
• Audio-out
• S/PDIF out (optical)
• USB 2.0 (service port)
• USB power
• RJ-45
• RS-232C
• 12V Trigger

Loop Through (Audio): Audio passthrough from HDMI
