Description
Camera Specifications:
- Image Sensor: 1/3″ Progressive Scan CMOS
- Max. Resolution: 2688 × 1520
- Min. Illumination:
- Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360°
Lens:
- Lens Type: Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV:
- 2.8 mm: Horizontal FOV 100.2°, Vertical FOV 54.7°, Diagonal FOV 119.7°
- 4 mm: Horizontal FOV 81.1°, Vertical FOV 44.7°, Diagonal FOV 94.6°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.0
- Depth Of Field:
- 2.8 mm: 1.9 m to ∞
- 4 mm: 2.5 m to ∞
DORI:
- 2.8 mm:
- Detection: D: 63 m, O: 25 m, R: 12 m, I: 6 m
- 4 mm:
- Detection: D: 78 m, O: 31 m, R: 15 m, I: 7 m
Illuminator:
- Supplement Light Type: IR
- Supplement Light Range: Up to 40 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
Video:
- Main Stream:
- 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream:
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) (Third stream is supported under certain settings.)
- Video Compression: Main stream: H.265/H.264/H.265+/H.264+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Type: Baseline Profile/Main Profile/High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR/VBR
- Scalable Video Coding (SVC): H.264 and H.265 encoding
- Region Of Interest (ROI): 1 fixed region for main stream and sub-stream
Audio:
- Audio Type: Mono sound
- Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Environment Noise Filtering: Yes
Network:
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
- User/Host: Up to 32 users. 3 user levels: administrator, operator, and user
- Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication, TLS 1.1/1.2, WSSE
Network Storage:
- NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- Supports memory card encryption and health detection with high-end Hikvision memory card
Client:
- iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
- Plug-in Required Live View: IE 10, IE 11
- Plug-in Free Live View: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Local Service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image:
- Image Parameters Switch: Yes
- Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
- Day/Night Switch: Day, Night, Auto, Schedule
- Wide Dynamic Range (WDR): 120 dB
- SNR: ≥ 52 dB
- Image Enhancement: BLC, HLC, 3D DNR
- Privacy Mask: 4 programmable polygon privacy masks
Interface:
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Built-In Microphone: Yes
- Reset Key: Yes
Event:
- Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
- Smart Event: Scene change detection
- Linkage: Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email
Deep Learning Function:
- Face Capture: Yes
- Perimeter Protection: Line crossing, intrusion, region entrance, region exiting; support alarm triggering by specified target types (human and vehicle)
General:
- Power:
- 12 VDC ± 25%, 0.45 A, max. 5.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
- PoE: IEEE 802.3af, Class 3, max. 7 W
- Material: Front cover: Metal, body: Metal, bracket: Metal
- Dimension: Ø74.4 mm × 179.2 mm (Ø2.9″ × 7.1″)
- Package Dimension: 234 mm × 120 mm × 117 mm (9.2″ × 4.7″ × 4.6″)
- Weight: Approx. 525 g (1.2 lb.), With Package Weight: Approx. 750 g (1.7 lb.)
- Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
- Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
- Language: Supports 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General Function: Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
- Approval:
- EMC: CE-EMC
- Safety: UL, CB, CE-LVD
- Environment: CE-RoHS
- Protection: IP67
