Description
Camera Specifications:
- Image Sensor: 1/1.8″ Progressive Scan CMOS
- Max. Resolution: 3200 × 1800
- Min. Illumination:
- Color: 0.0005 Lux @ (F1.0, AGC ON)
- 0 Lux with light
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
Lens:
- Lens Type: Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV:
- 2.8 mm: Horizontal FOV 108.8°, Vertical FOV 56.4°, Diagonal FOV 134.3°
- 4 mm: Horizontal FOV 93.3°, Vertical FOV 47.2°, Diagonal FOV 114.2°
- Lens Mount: M16
- Iris Type: Fixed
- Aperture: F1.0
- Depth Of Field:
- 2.8 mm: 3.3 m to ∞
- 4 mm: 3.8 m to ∞
DORI:
- 2.8 mm:
- Detection: D: 89 m, O: 35 m, R: 17 m, I: 8 m
- 4 mm:
- Detection: D: 109 m, O: 43 m, R: 21 m, I: 10 m
Illuminator:
- Supplement Light Type: IR, White Light
- Supplement Light Range: Up to 30 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
Video:
- Main Stream:
- 50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 24 fps (3200 × 1800), 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream:
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
- Third Stream:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) (Third stream is supported under certain settings.)
- Video Compression: Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264 (Third stream is supported under certain settings.)
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline Profile, Main Profile, High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR, VBR
- Scalable Video Coding (SVC): H.264 and H.265 encoding
- Region Of Interest (ROI): 1 fixed region for mainstream and sub-stream
Audio:
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Type: Mono sound
- Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Environment Noise Filtering: Yes
Network:
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
- User/Host: Up to 32 users, 3 user levels: administrator, operator, and user
- Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication, watermark, IP address filter, basic and digest authentication, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication
Network Storage:
- NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
Client:
- iVMS-4200, Hik-Connect
Web Browser:
- Plug-in Required Live View: IE 10, IE 11
- Plug-in Free Live View: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Local Service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image:
- Image Parameters Switch: Yes
- Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR, Defog
- SNR: ≥ 52 dB
- Wide Dynamic Range (WDR): 130 dB
- Privacy Mask: 4 programmable polygon privacy masks
Interface:
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Built-In Microphone: Yes, 1 built-in microphone
- Built-In Speaker: Max. power consumption: 1.2 W, max. sound pressure level: 10 cm: 95 dB
- Audio:
- 1 input (line in), two-core terminal block
- Max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium
- 1 output (line out), two-core terminal block
- Max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
- Alarm: 1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
- Reset Key: Yes
Event:
- Basic Event: Motion detection, video tampering alarm, exception
- Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning, strobe light
- Smart Event: Scene change detection, Face Capture, Perimeter Protection (Line crossing, intrusion, region entrance, region exiting)
General:
- Power:
- 12 VDC ± 25%, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug, reverse polarity protection
- PoE: IEEE 802.3af, Class 3, max. 10.5 W
- Material: Cover: metal, main body: metal
- Dimension: Ø138.3 mm × 115.4 mm (Ø5.4″ × 4.5″)
- Package Dimension: 170 mm × 170 mm × 160 mm (6.7″ × 6.7″ × 6.3″)
- Weight: Approx. 820 g (1.8 lb.), With Package Weight: Approx. 1316 g (2.9 lb.)
- Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- General Function: Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
- Language: Supports 33 languages
- Approval: EMC, Safety, Environment
- Protection: IP67
