Description

Camera Specification:

Image Sensor:

• Sensor Type: 1/1.8″ 3K CMOS
• Signal System: PAL/NTSC
• Maximum Resolution: 2960 (H) × 1665 (V)
• Minimum Illumination: 0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter Time: PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s

Light and Angle Adjustment:

• Light Alarm: Solid Light Alarm (White Light)
• Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°

Lens Information:

• Lens Type: 2.8 mm and 3.6 mm fixed focal lens
• Focal Length & FOV:
  • 2.8 mm: Horizontal FOV: 112°, Vertical FOV: 60°, Diagonal FOV: 133°
  • 3.6 mm: Horizontal FOV: 95°, Vertical FOV: 50°, Diagonal FOV: 115°
• Lens Mount: M16

Image and Video Features:

• Frame Rate: 3K@20fps, 4MP@25fps/30fps, 1080p@25fps/30fps
• Wide Dynamic Range (WDR): ≥130 dB
• White Light: Auto/Off
• Image Parameters Switch: STD/HIGH-SAT/HIGHLIGHT
• AGC: Yes
• Day/Night Mode: Color
• White Balance: Auto/Outdoor/Global/Manual
• Image Enhancement: WDR;BLC;HLC;Global;HLS
• Privacy Mask: 4 programmable privacy masks
• Noise Reduction: 3D DNR/2D DNR
• Image Settings: Anti-Banding;Mirror;Contrast;Brightness;Smart Light

Interface and Event Handling:

• Video Output: 1 HD analog output
• Event Detection: Motion Detection with 4 programmable motion areas

General Information:

• Language: English
• Operating Conditions: -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
• Power Supply: 12 VDC ± 25%/PoC.at (Power over Coax)
• Power Consumption: Maximum 3.4 W
• Material: Metal
• White Light Range: Up to 20 m
• Communication: HIKVISION-C
• Dimension: 161.1 mm × 70 mm × 70 mm (6.34″ × 2.76″ × 2.76″)
• Weight: Approximately 434 g (0.96 lb.)

Approval and Protection:

• Protection Rating: IP67
