Description

Camera Specifications:

• Image Sensor: 1/1.8″ Progressive Scan CMOS
• Max. Resolution: 2688 × 1520
• Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
• Shutter Time: 1/3 s to 1/100,000 s

Angle Adjustment:

• Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Day & Night:

• IR cut filter

Lens:

• Focal Length & FOV: 2.8 mm (111.9°), 4 mm (95.2°), 6 mm (58.4°)
• Lens Type: Fixed focal lens (2.8, 4, and 6 mm optional)
• Lens Mount: M16
• Iris Type: Fixed
• Aperture: F1.0
• Depth Of Field: 2.8 mm (3.1 m to ∞), 4 mm (5.4 m to ∞), 6 mm (12.1 m to ∞)

DORI:

• 2.8 mm: D: 58.2 m, O: 23.1 m, R: 11.6 m, I: 5.8 m
• 4 mm: D: 77 m, O: 30.5 m, R: 15.4 m, I: 7.7 m
• 6 mm: D: 115.6 m, O: 45.9 m, R: 23.1 m, I: 11.6 m

Illuminator:

• Supplement Light Type: IR, White Light
• Supplement Light Range: Up to 40 m
• Smart Supplement Light: Yes
• IR Wavelength: 850 nm

Video:

• Main Stream: 50 Hz – 25 fps, 60 Hz – 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
• Sub-Stream: 50 Hz – 25 fps, 60 Hz – 30 fps (1280 × 720, 640 × 480, 640 × 360)
• Third Stream: 50 Hz – 10 fps, 60 Hz – 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• Video Compression: H.265/H.264/H.265+/H.264+/MJPEG
• Video Bit Rate: 32 Kbps to 8 Mbps
• H.264 Type: Baseline Profile, Main Profile, High Profile
• H.265 Type: Main Profile
• Bit Rate Control: CBR, VBR
• Scalable Video Coding (SVC): H.264 and H.265 encoding

Region Of Interest (ROI):

• 1 fixed region for mainstream and sub-stream

Audio:

• Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
• Audio Type: Mono sound
• Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw), 16 Kbps (G.722.1), 16 Kbps (G.726), 32 to 192 Kbps (MP2L2), 8 to 320 Kbps (MP3), 16 to 64 Kbps (AAC-LC)
• Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
• Environment Noise Filtering: Yes

Network:

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
• Simultaneous Live View: Up to 6 channels
• API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
• User/Host: Up to 32 users (3 user levels: administrator, operator, and user)

Security:

• Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE, and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)

Network Storage:

• NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
• Client: iVMS-4200, Hik-Connect
• Web Browser: Plug-in required live view – IE 10, IE 11; Plug-in free live view – Chrome 57.0+, Firefox 52.0+, Edge 89+; Local service – Chrome 57.0+, Firefox 52.0+, Edge 89+

Image:

• Image Parameters Switch: Yes
• Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
• Day/Night Switch: Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR): 130 dB
• SNR: ≥ 52 dB
• Image Enhancement: BLC, HLC, 3D DNR, Defog
• Privacy Mask: 4 programmable polygon privacy masks

Interface:

• Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
• Built-In Microphone: Yes, 1 built-in microphone
• On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Built-In Speaker: Max. power consumption: 1.2 W, max. sound pressure level: 10 cm – 95 dB.
• Reset Key: Yes

Event:

• Basic Event: Motion detection (support alarm triggering by specified target types – human and vehicle), video tampering alarm, exception
• Smart Event: Scene change detection
• Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning, strobe light

Deep Learning Function:

• Face Capture: Yes
• Perimeter Protection: Line crossing, intrusion, region entrance, region exiting
• Support alarm triggering by specified target types (human and vehicle)

General:

• Power: 12 VDC ± 25%, 0.54 A, max. 6.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 8 W
• Material: Metal
• Dimension: Ø74.4 mm × 179.2 mm (Ø2.9″ × 7.1″)
• Package Dimension: 234 mm × 120 mm × 117 mm (9.2″ × 4.7″ × 4.6″)
• Weight: Approx. 510 g (1.1 lb.)
• With Package Weight: Approx. 880 g (1.9 lb.)

Storage Conditions:

• Temperature: -30 °C to 60 °C (-22 °F to 140 °F)
• Humidity: 95% or less (non-condensing)

Startup And Operating Conditions:

• Temperature: -30 °C to 60 °C (-22 °F to 140 °F)
• Humidity: 95% or less (non-condensing)

Language:

• 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function:

• Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding

Approval:

• Safety: UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
• Environment: CE-RoHS: 2011/65/EU
• EMC: CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
• Protection: IP67: IEC 60529-2013

Note: This comprehensive camera system ensures high-quality imaging, robust security features, and user-friendly controls, making it an ideal choice for various surveillance applications.
