Physical Details

• Tunnel size: 650mm (W) x 500mm (H)
• Conveyor speed: 0.22m/s
• Conveyor belt load rating: 150kg evenly distributed
• Spatial resolution: H/V dia 1.0mm
• Penetration: dia 0.160mm/34AWG
• Wire penetration: dia 0.102mm wire
• Leakage dose per inspection: ≤ 2.67 µGy
• Beam direction: bottom beam
• Tube current: 0.6 – 1.2 mA (adjustable)
• Tube voltage: 160KV (adjustable)
• Cooling/Working cycle: sealed oil cooling/100%

X-ray Generator

• Control interface: analog interface
• Tube voltage: 140-160 KV (adjustable)
• Tube current: 0.6-1.2 mA (adjustable)
• Cooling method: sealed oil cooling, industrial fan cooling
• Work cycle: 100%, no need to warm up
• Protection function: over voltage, over current, over temperature protection

Image Performance System

• Color image display: According to the material, pseudo color display
• Edge enhancement: Object contour edges are sharper
• Super image enhancement: Image edge details are clearer
• High penetration display: Improve the contrast of bright area in the image, make the easily penetrable area clearer
• Low penetration display: Improve the contrast of the dark area in the image and make the hard to penetrate area clearer
• Lighten/darken: Increase image brightness/decrease image brightness
• Magnifying lens: Local amplification function, dynamic real-time 100 level amplification
• Image pull back/forward: Display the first 10 images, and the image can be any image processing
• Image restoration: One click image display to restore the original
• Image store: High speed electronic hard disk, the default supports 5,000,000 image storage, continuous work to save

Video Surveillance System – HD Resolution Photography

The X-Ray Scanner device must have integrated the camera system inside the body without being detected from the outside, which cameras make the recording/recording of the person and the luggage at the time of installation on the conveyor belt of the device as
