Description

Specifications of ACCESS POINT – UNIFI AP AC LITE

Wireless Network

• Standards: 802.11a/b/g/n/ac
• MIMO: 2.4GHz 2×2, 5GHz 2×2
• 2.4GHz Radio Rate: 300Mbps
• 5GHz Radio Rate: 867Mbps

Interfaces

• RJ45 Ports: (1) 1 Gbps

Power

• Power Method: 24V Passive PoE, 802.3af PoE
• Power Supply: External PoE Adapter
• Supported Input Voltage: 20 – 28 V DC
• Max Power Consumption: 7 W

Physical Parameters

• Dimensions: Ø160 x 31.45 mm
• Weight: 0.185 kg
• Operating Temperature: -10 °C to 70 °C
• Environment: Indoor
• Mounting Method: Wall Mount, Ceiling Mount

The UniFi AC Lite AP offers dual-radio performance with gigabit speeds and features advanced RF performance and configuration options for optimal placement and troubleshooting. It’s designed for high-density client deployments and can be managed using the UniFi Network Application.
