Description

The 802.11ac Wave 2 MU-MIMO (Multi-User, Multiple Input, Multiple Output) technology enables a Wave 2 AP to communicate with multiple clients simultaneously, significantly boosting multi-user throughput and enhancing the overall user experience.

UniFi is a groundbreaking Wi-Fi system that combines enterprise-level performance, limitless scalability, and a central management controller. The UniFi AC HD AP boasts an elegant industrial design and can be easily installed using the provided mounting hardware.

Accessible through any standard web browser, the UniFi Controller software is a robust engine suitable for high-density client deployments that require low latency and reliable performance.

Powerful Hardware

The UniFi AC HD AP incorporates the latest Wi-Fi 802.11ac Wave 2 MU-MIMO technology.

Easy Mounting

Its sleek design seamlessly integrates into any environment, with all necessary accessories included. The unique LED provisioning ring or square aids in administrator location tracking and device alerts.

Power over Ethernet (PoE)

This device comes with PoE functionality, and each single pack includes a PoE adapter. UniFi devices can be powered with a separate UniFi Switch (available in 24- and 48-port versions with various power output options), which offers auto-sensing IEEE 802.3af PoE / 802.3at PoE+ and configurable 24V passive PoE.

UniFi Controller

Utilize the UniFi controller to centrally configure and manage any number of UniFi access points, map your WiFi networks, control network traffic, or integrate new UniFi access points into your network. With a UniFi controller, you can manage and control multiple sites in different locations separately, providing you with the best possible overview.

Technical Data:

Manufacturer / Product: Ubiquiti Networks / UniFi AP AC HD (UAP-AC-HD) Networking

Interface: 2 x 10/100/1000

Ethernet Port WiFi Frequency: 2.4 GHz / 5GHz WiFi

Standards: 802.11 a/b/g/n/ac/ac-wave2

TX Power: 6-25 dBm

Antennas: 3 x Dual-Band Antennas, 2.4 GHz: 3 dBi, 5 GHz: 4 dBi max.

Power Consumption: 17W Power

Supply: 48V PoE – 802.3af/803.2at (Supported Voltage

Range: 44 to 57VDC)

Dimensions: 220 x 220 x 48.1 mm

Weight: 700g (830g with Mounting Kits)

Appliance: Indoor / Outdoor Operating

Temperature: -10°C to 70°C Operating

Humidity: 5 – 95% Noncondensing

Scope of delivery: 1 x Ubiquiti UniFi AP AC HD (UAP-AC-HD) 1 x 48V, 0.5A Gigabit PoE Adapter 1 x Wall/Ceiling Mounting Kit
