Description

Camera:

• Image Sensor: 5 MP CMOS
• Max. Resolution: 2560 (H) × 1944 (V)
• Min. Illumination: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter Time: PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
• Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
• Signal System: PAL/NTSC

Lens:

• Lens Type: 2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV:
  • 2.8 mm:
    • Horizontal FOV: 99.7°
    • Vertical FOV: 72°
    • Diagonal FOV: 139.8°
  • 3.6 mm:
    • Horizontal FOV: 80.1°
    • Vertical FOV: 58.6°
    • Diagonal FOV: 106.2°

Illuminator:

• Supplement Light Type: White Light
• Supplement Light Range: Up to 40 m
• Smart Supplement Light: Yes

Image:

• Image Parameters Switch: STD/HIGH-SAT
• Image Settings: Brightness, Mirror, Sharpness, Anti-Banding, AGC
• Frame Rate:
  • 5 MP @ 20 fps
  • 4 MP @ 30 fps
  • 4 MP @ 25 fps
  • 1080p @ 30 fps
  • 1080p @ 25 fps
• Day/Night Mode: Color
• Wide Dynamic Range (WDR): ≥130 dB
• Image Enhancement: WDR, BLC, HLC, Global, HLS
• Noise Reduction: 3D DNR/2D DNR
• White Balance: Auto/Manual

Interface:

• Video Output: 1 HD analog output

General:

• Material: Metal
• Dimension: 82.6 mm × 77.1 mm × 220.4 mm (3.25″ × 3.04″ × 8.68″)
• Weight: Approx. 600 g (1.32 lb.)
• Operating Condition: -40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing)
• Communication: HIKVISION-C
• Language: English
• Power: 12 VDC±25%/PoC.at, Max. 5.4 W
  • Note: You are recommended to use one power adapter for one camera, and use a 2-pin power supply for long-distance power supply.
• Approval: IP67
