Description

Camera Specifications

Image Sensor

• Utilizes a 5 MP CMOS image sensor.
• Offers a maximum resolution of 2560 (H) × 1944 (V).

Low Light Performance

• Minimum illumination of 0.0005 Lux @ (F1.0, AGC ON), ensuring clear images even in low-light conditions.

Shutter Time

• PAL: 1/25 s to 1/50,000 s
• NTSC: 1/30 s to 1/50,000 s
• Provides precise control over exposure.

Day & Night Mode

• Supports color imaging for 24/7 surveillance.

Angle Adjustment

• Pan: 0° to 360°
• Tilt: 0° to 75°
• Rotation: 0° to 360°
• Allows flexible positioning for optimal coverage.

Signal System

• Compatible with both PAL and NTSC signal systems.

Lens Details

Lens Type

• Equipped with a 2.8 mm fixed lens.

Field of View (FOV)

• Horizontal FOV: 99.7°
• Vertical FOV: 72°
• Diagonal FOV: 139.8°

Illuminator

Supplement Light Type

• Uses white light for supplementary illumination.

Effective Range

• Provides a supplement light range of up to 20 meters.

Image Features

Image Parameters Switch

• Switch between standard and high saturation image parameters.

Image Settings

• Adjust brightness, sharpness, mirror, smart light, and AGC settings for optimal image quality.

Frame Rate

• Supports various frame rates including TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080p@30fps, 1080p@25fps; CVI: 4MP@30fps, 4MP@25fps; AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps; CVBS: PAL/NTSC.

Wide Dynamic Range (WDR)

• Provides a dynamic range of ≥130 dB for capturing detailed images in high-contrast scenes.

Image Enhancement

• Includes BLC and HLC for enhancing image quality.

White Balance

• Offers auto and manual white balance modes for accurate color reproduction.

Interface

Video Output

• Equipped with a switchable TVI/AHD/CVI/CVBS video output for versatile connectivity.

General Specifications

Material

• Main body: Metal
• Enclosure: Plastic

Dimension and Weight

• Measures Φ 109.82 mm × 85.56 mm (4.32″ × 3.37″)
• Weighs approximately 350 g (0.77 lb.)

Operating Condition

• Operating temperature: -40°C to 60°C (-40°F to 140°F)
• Humidity tolerance: 90% or less (non-condensing)

Communication

• Supports HIKVISION-C communication protocol for seamless integration.

Language

• User interface available in English for easy operation.

Power

• Powered by 12 VDC ± 25%, with a maximum power consumption of 3.5 W.
• It is recommended to use one power adapter per camera.

Approval

• Certified IP67 for protection against dust and water ingress.
