Description

Motion Detection and Video Analysis System

Motion Detection and Analysis

• Motion Detection 2.0: Utilizes advanced motion detection technology.
• Human/Vehicle Analysis: Supports analysis of human and vehicle movements.
• Number of Channels: 4

Video and Audio Inputs

• IP Video Input: 8-ch
• Incoming Bandwidth: 80 Mbps
• Outgoing Bandwidth: 80 Mbps

HDMI and VGA Output

• HDMI Output:
  • 1-ch, 4K (4096 x 2160)/30 Hz
  • 4K (3840 x 2160)/30 Hz
  • 2K (2560 x 1440)/60 Hz
  • 1920 x 1080/60 Hz
  • 1600 x 1200/60 Hz
  • 1280 x 1024/60 Hz
  • 1280 x 720/60 Hz
• VGA Output:
  • 1-ch, 1920 × 1080/60 Hz
  • 1280 × 1024/60 Hz
  • 1280 × 720/60 Hz
• Video Output Mode: HDMI/VGA simultaneous output

Audio Features

• Audio Output: 1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 k Ω)
• Audio Compression: H.265+, H.265, H.264+, H.264

Decoding Capabilities

• Decoding Format: H.265+, H.265, H.264+, H.264
• Recording Resolution: 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Decoding Capability: 1-ch@8 MP (30 fps)/5-ch@1080p (30 fps)
• Synchronous Playback: 8-ch
• Maximum Resolution Restriction: The length or width of camera resolution (each track) cannot exceed 4096 pixels.

Network Connectivity

• Stream Type: Video, Video & Audio
• Remote Connection: 32
• Network Protocol: TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
• Network Interface: 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
• PoE Interface: 8-ch; 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
• PoE Standard: IEEE 802.3 af/at

Storage and USB Interface

• SATA Interfaces: 2; 2 SATA interfaces
• Capacity: Up to 8 TB capacity for each disk
• USB Interface: 2 × USB 2.0

Power and General Information

• Power Supply: 48V, 2.5A MAX
• Power Consumption: ≤ 15W
• Working Temperature: -10 to +55º C (+14 to +131º F)
• Working Humidity: 10% to 90%

Chassis

• Chassis Type: 1U
• Dimensions (W × D × H): 385 × 315 × 52 mm (15.2″× 12.4″ × 2.0″)
• Weight: ≤ 2.6 kg (5.7 lb)
